Plastic pellet dehydrator machine

Plastic pellet dehydrator machine



plastic dehydrator machine

Dehydrator machine –To remove water after washing
Introduction:
The plastic pellet dehydrator machine uses spiral, push-up, separation and dehydration, and automatically feeds and discharges in one time.
Suitable for polyester sheets, cable skins, wire tubes, etc.

Working principle:
The PP particles after blanching contain a certain amount of water and cannot be used directly. The plastic pellet dehydrator machine is mainly used for the dehydration function of PP pellets, so that the finished product can meet the storage requirements. The wet PP particles are gradually raised by the auger of the plastic pellet dehydrator machine, and more water is extracted by the principle of high-speed rotation. The machine can automatically feed and discharge, no need for manual operation, and greatly improve work efficiency.
Use range:
PET pellets, polyester sheets, wire tubes, cable skins, etc.

plastic dehydrator machine
plastic dehydrator machine
plastic dehydrator machine

Parameter:

Model Capacity(kg) Size(mm) Heating
(kw)
Blower
(kw)
Dimensions(mm)
Path High
SL-12 12 255 390 1.5 0.06 510*300*660
SL-25 25 345 425 3 0.12 760*420*851
SL-50 50 420 550 4.5 0.18 860*500*920
SL-75 75 495 630 6 0.3 940*540*1140
SL-100 100 560 630 6 0.3 1050*640*1235
SL-150 150 600 850 9 0.4 1075*700*1400
SL-200 200 700 850 11 0.4 1210*750*1500
SL-300 300 830 1030 15 0.5 1220*800*1630
SL-400 400 894 1040 15 0.5 1450*940*1800

Function::
The plastic pellet dehydrator machine is a simple and effective cleaning and dewatering equipment for recycling waste plastics. It plays an important role in the transportation process. At the same time, the plastic pellet dehydrator machine completely replaces the feeding link and adds cleaning and high-speed dewatering functions, called advanced automated flow production equipment.

Features
1.Stainless steel structure prevents the material from being polluted.
2.Aluminum crust, effective thermal insulating
3.The hopper can be separaed from the stand for easy cleaning.
4.High output and dryness
5.High precision temperature controller to control temperature accurately.

Specifications:
1.This plastic pellet dehydrator machine is widely applicable to dewatering for crushed material of plastic, just like PET bottles,flakes,  sheet, etc.
2.Tscreen, using high quality stainless steel material, rotor and body, equipment is durable;
3.Tproduction of advanced technology, the spindle through dynamic and static balance, rational design, low noise, easy to clean, you can easily open the body, remove dryer internal sieve impurities;
4.Good dewatering effect, less power consumption and efficiency, continuous production, high degree of automation, saving;
5.In addition to dehydration, plastic pellet dehydrator machine can wash the plastic micro-small debris such as sand.
