Owner’s Manual for Plastic pelletizing machine

Owner’s Manual for Plastic pelletizing machine



The first. Requirements on clothes and matters needing attention
1. Wear working clothes, masks, protective glasses and gloves during working.
2. Be careful for hand pinching when feeding materials into granulator.
3. Do not put your hand into the electrical chamber during running.
4. Do not open the outlet hopper during operation.

Second. Cleaning before use and after being shutdown
1.Before inspection, unplug the power supply of plastic pelletizing machine.
2.Open the cover plate of the plastic granulator, use the brush to clean the impurities inside the granulator, and then use compressed air to clean thoroughly, then make sure that there is no impurities in granulator.

plastic pellet making machine

Third. Pre-check
1.Unplug before checking. Check whether the ground wire is connected.
2.Open the cover of plastic granulator and the enclosure of stationary blades, drive the knife toward your own direction manually to check the bearings of moving blades, lubrication between gears, and the clearance between moving blade, the elasticity of triangular belt.
3.Check whether the hob are damaged or not and whether the rubber roller is in good condition.
4.Close the enclosure of the stationary cutter and the cover of the plastic granulator, connect the power supply, check all electrical components and the rotating condition of the granulator, then adjust the plastic granulator to the positive rotation direction.
5.Check whether electric wire connecting screw is tight or not. Make sure all parts of the plastic granulator are in good condition before starting up. The equipment maintenance should be ran after the fault report sending to the equipment supervisor.

Fourth. Operation steps
1.The plastic pelletizing machine can be carried out cleaning after inspection is completed.
2.Start the plastic granulator, start the motor first before starting the cutter carefully.
3.Start the plastic granulator at low speed for 2 minutes with the proper running ensured.
4.Pull the extruded materials into the plastic granulator to process into granules, and the grain thickness is between 2 and 4mm.
5.Adjust the speed of plastic granulator according to the process to match the speed of plastic granulator and extrusion.
6.When the work is finished, evacuate materials and slow down the cutter speed until it stops. Then turn off the motor.
7.Clean the working environment around the plastic granulator in time.
